Description
| ZBF150DC SOLAR DIRECT DRIVE BLOOD BANK REFRIGERATOR WITH SURE CHILL® TECHNOLOGY | ||
| Application: | Blood Bank Refrigerator | |
| Cold Chain Compliant | YES | |
| Type of Appliance | Ice lined (water lined) Solar direct drive refrigerator | |
| Manufactured in: | South Africa | |
| IEC 60335 Compliant | YES | |
| Specifications | ||
| Gross Volume (L) | 173 | |
| Blood Bag Storage | 72 x 450ml Blood bags | |
| Hot Zone Appliance (+43°C) | YES | |
| Refrigerant | R134a (CFC Free) | |
| Min rated ambient temp | +5°C | |
| Energy Source | Solar direct drive | |
| Fuel and cycle type | Electric – compression | |
| Temperature Indicator | External Solar thermometer | |
| Temp Range | 2°C to 6°C | |
| Drawers | 6 | |
| For solar direct drive units, the correct sizing of the solar panel array for a specific site is complex and critical. It must be agreed with both the appliance manufacturer and with the qualified supplier of the solar energy system at the time of ordering. | ||
| Performance Information | ||
| Autonomy Time at +43°C (Not fully Charged) | >100 Hours | |
| At a Solar Radiation Reference Period of | 3.5 kWh/h/m2/day | |
| *** Sure Chill ® Technology guarantees that blood cannot and will not freeze within rated temperatures (+5°C to +43°C) | ||
| Accessories | Liquid PCM to mix with water | |
| Optional Extras | Drawers, Plywood packaging, 2 padlocks | |
| Dimensions | ||
| Unboxed Dimensions (mm) | (H) 1880mm x (W) 800mm x (D) 700mm | |
| Shipping Volume | 1.22 m³ | |
| Shipping Weight | 180kg | |
| Temperature Control | Temperature accuracy is exceptionally high; temperature varies by less than 1°C throughout the refrigerated compartment during compressor cycling and holdover. | |
| Spares per 10 units | Compressor, IMPC151 | |
| Compressor controller, IMP152 | ||
| Condenser, IMP145 | ||
| Fan, IMP144 | ||
| Electronic controller (thermostat), IMP012 | ||
